SteerCATH Steerable Catheter
A steerable support catheter with deflectable tip, designed for complex or branch vessel access in coronary and peripheral interventions. Enhances crossing success in challenging anatomies.
SteerCATH offers a steerable guiding catheter system engineered to improve access to difficult-to-reach vascular anatomies, streamlining diagnostic and interventional procedures across a broad range of clinical applications. By uniting flexible materials, a precise steering mechanism, and varied size options, SteerCATH enables physicians to quickly and accurately navigate complex vessel pathways, enhancing procedural efficiency and patient outcomes.
Steerable Catheter Shaft
- Directional Control: The deflectable distal segment empowers clinicians to steer and position the catheter tip with finesse, minimizing the need for multiple device exchanges.
- Optimized Flexibility: Allows for smooth transitions through challenging anatomies, reducing vessel trauma and risk of intimal dissection.
Wide Range of Inner Diameters
- 4F to 14F: Accommodates a variety of procedural requirements, from diagnostic imaging to interventional therapies.
- Secure Device Compatibility: Maintains sufficient lumen space for contrast injection, wire exchanges, or ancillary device delivery.
Multiple Length Options
- Usable Lengths: 45 cm, 55 cm, or 90 cm, offering flexibility to handle short or long vascular anatomies.
- Enhanced Reach: Extends the catheter’s operational range to deeper vessels, facilitating improved lesion access or distal interventions.
High-Performance Materials
- Robust Shaft Construction: Balances pushability and torque control, ensuring stable navigation in tortuous vessels.
- Smooth Inner Lumen: Minimizes friction when advancing guidewires or device components, contributing to reduced procedure times.
General Product Specifications
Specification | Detail / Value |
Product Name | SteerCATH Steerable Catheter |
Intended Use | Provides steerable distal tip control for complex vessel navigation in coronary, peripheral, or structural cases |
Catheter Design | Deflectable tip (uni- or bidirectional), braided shaft for torque response |
Material | Pebax/Polyamide shaft with stainless steel or nitinol braiding, PTFE inner liner |
Outer Diameter (Fr) | 5F, 6F, 7F (depending on model) |
Working Length | Typically 90–110 cm (can vary by product code) |
Deflection Mechanism | Handle-based pull-wire system, providing up to 180° distal tip deflection |
Radiopaque Markers | 1–2 near distal tip for precise fluoroscopic positioning |
Guidewire Compatibility | 0.014” or 0.018” (depending on lumen diameter) |
Maximum Injection Pressure | ~1000 psi (varies by French size) |
Sterility | Sterile (Ethylene Oxide) |
Single Use | Yes |
Shelf Life | 2–3 years (typical, if packaging remains intact) |
Operating Temperature | Recommended 15–25 °C, store away from direct sunlight |
Clinical Indications | Branch vessel cannulation, crossing tortuous anatomies, guiding device placement |
Contraindications | Extremely tight or calcified lesions preventing safe catheter passage, known material allergies, etc. |
5F SteerCATH
French Size | Working Length (cm) | Deflection | Guidewire Compat. | Product Code | Notes |
5F | 90 | Uni 120° | 0.014” | STC-5F-90-U120 | Short length, moderate tip bend |
5F | 90 | Bi 90° / 90° | 0.014” | STC-5F-90-B90 | Bidirectional deflection for multi-plane approach |
5F | 100 | Uni 160° | 0.014” | STC-5F-100-U160 | Longer working length, higher deflection |
5F | 110 | Bi 120° / 120° | 0.014” | STC-5F-110-B120 | Max deflection for complex distal branches |
6F SteerCATH
French Size | Working Length (cm) | Deflection | Guidewire Compat. | Product Code | Notes |
6F | 90 | Uni 120° | 0.014” / 0.018” | STC-6F-90-U120 | Common size for coronary or peripheral combos |
6F | 90 | Bi 90° / 90° | 0.014” / 0.018” | STC-6F-90-B90 | Bidirectional tip control |
6F | 100 | Uni 160° | 0.014” / 0.018” | STC-6F-100-U160 | Extended length, high deflection angle |
6F | 100 | Bi 120° / 120° | 0.014” / 0.018” | STC-6F-100-B120 | Ideal for complicated anatomical curves |
6F | 110 | Uni 180° | 0.014” / 0.018” | STC-6F-110-U180 | Maximum unidirectional bend for challenging lesions |
6F | 110 | Bi 135° / 135° | 0.014” / 0.018” | STC-6F-110-B135 | Highest bidirectional deflection capacity |
7F SteerCATH
French Size | Working Length (cm) | Deflection | Guidewire Compat. | Product Code | Notes |
7F | 90 | Uni 120° | 0.014” / 0.018” | STC-7F-90-U120 | Suited for larger vessel approach, robust torque |
7F | 90 | Bi 90° / 90° | 0.014” / 0.018” | STC-7F-90-B90 | Bidirectional, short length for quick access |
7F | 100 | Uni 160° | 0.014” / 0.018” | STC-7F-100-U160 | Extended length, high unidirectional bend |
7F | 100 | Bi 120° / 120° | 0.014” / 0.018” | STC-7F-100-B120 | Multi-plane deflection for complex anatomies |
7F | 110 | Uni 180° | 0.014” / 0.018” | STC-7F-110-U180 | Max bend, ideal for peripheral or tall patients |
7F | 110 | Bi 135° / 135° | 0.014” / 0.018” | STC-7F-110-B135 | Highest dual deflection angles in 7F platform |
