Invaducer Intraducer
A titanium or alloy sternal plate system providing rigid fixation post-midline sternotomy, enhancing sternal stability and reducing infection or dehiscence risks after cardiac surgery.
The Invaducer Intraducer by INVAMED represents the crucial first step in vascular interventions, enabling secure and controlled entry into the arterial or venous system. Developed to streamline angiographic procedures, this introducer meets all needs for opaque and fluid delivery while maintaining high quality standards for safe, user-friendly vascular access.
Robust Angiography Access
- Designed for introductory access to peripheral or central vessels, laying the foundation for catheter-based interventions.
- Ideal for angiography procedures where contrast media and specialized fluids must be introduced securely and repeatedly.
High-Quality, Smooth Insertion
- Crafted from medical-grade polymers for a low-friction surface, facilitating a gentle vessel entry.
- Minimizes vessel trauma and reduces the risk of complications like dissection or spasm.
Radiopaque & Fluid Management
- The hub and distal tip incorporate radiopaque markers, allowing real-time visualization under fluoroscopy.
- Engineered for leak-free fluid connections, ensuring accurate contrast injection and controlled fluid administration.
Secure Hemostasis Valve
- Each introducer set features a hemostatic valve and optional side-arm adapter, preventing excessive blood loss while permitting device exchanges.
- Enhances procedural efficiency by simplifying guidewire or catheter manipulations without repeated vascular punctures.
Multiple Sizes & Lengths
- Offered in various French sizes and lengths, supporting a range of vascular anatomies and access site preferences (radial, femoral, brachial).
- Color-coded hubs for immediate gauge recognition, aiding in quick identification during complex angiographic procedures.
Sterile, Single-Use
- Each Invaducer package comes sterile and single-use, guaranteeing consistent performance and eliminating reprocessing burdens.
- Complies with stringent quality controls, ensuring safe introduction even in critical cardiovascular interventions.
Technical Specifications
Specification | Detail / Value |
Product Name | Invaducer Intraducer (INVAMED) |
Intended Use | Introducer sheath system for vascular access (peripheral or central) in angiographic and interventional procedures |
Materials | Medical-grade polymer sheath, soft tip for vessel protection, radiopaque markers |
Available French Sizes | Ranging from ~4F to 9F (verify local SKU for exact range) |
Sheath Lengths | Commonly 7 cm–45 cm (shorter or longer versions subject to procedural demands) |
Hemostasis Valve | Integrated valve with side-port, enabling repeated device insertions with minimal blood loss |
Radiopacity | Distal tip or entire sheath portion (depending on model) is radiopaque for fluoroscopic visualization |
Sterility | Single-use, sterile packaging (EtO or gamma sterilized) |
Shelf Life | Indefinite under proper storage; check packaging integrity before use |
Size & Ordering Matrix
French Size | Sheath Length (cm) | Introducer Type | Hemostasis Valve | Product Code | Notes |
4F | 7, 11 | Standard Radiopaque Tip | Yes | IV-04-[Length]-STD | Ideal for radial access or small vessel procedures |
5F | 11, 23 | Radiopaque + Side Port | Yes | IV-05-[Length]-SP | Common gauge for diagnostic angiograms and moderate interventions |
6F | 11, 23 | Radiopaque + Side Port | Yes | IV-06-[Length]-SP | Popular for coronary interventions, supports multiple catheters |
7F | 23, 45 | Radiopaque + Enhanced Valve | Yes | IV-07-[Length]-EV | Suited for complex peripheral or coronary procedures requiring larger catheters |
8F | 23, 45 | Radiopaque + Enhanced Valve | Yes | IV-08-[Length]-EV | For heavier interventions, structural heart procedures, or advanced endovascular |
9F | 45 | Radiopaque + Enhanced Valve | Yes | IV-09-45-EV | Extended length for deep femoral or alternative large-vessel approaches |
